3D models, visualisation & 3D printing

3D models & visualisation

The model is the single source of truth

We build precise 3D models of products, equipment and spaces — engineering models for further detailing, concept views for presentations or digital prototypes to validate an idea before execution.

A render in a quote sells better than a table: a clear picture early on saves time, speeds up decisions and reduces the chance of error.

SLDPRT · SLDASMSTEP · IGESSTL · 3MFOBJ · FBXPNG · JPG · PDF

3D model of a plant room — 3D layout · mechanical servicesPlant room modelled in 3D before execution — clash-free piping, equipment access and service space checked on screen, not on site.

3D model of a water treatment unit — Product model · for productionWater treatment unit — frame, vessels, piping; the model from which shop drawings and BOM are derived.

Interior visualisation — Visualisation · for quotesPhotorealistic render — equipment and space as the client will see it, before a single part is made.

What we model

Four kinds of 3D work

Same tools, different purpose — the model is built for what it has to do: feed a drawing, win a quote, fit a plant room or become a physical part.

Engineering modelParametric parts and assemblies in SolidWorks — sheet metal, weldments, mechanisms. Built to produce drawings and BOMs.

Render & visualisationPhotorealistic images and exploded views for quotes, tenders, catalogues and presentations.

3D layout of plantsPlant rooms, lines and equipment arranged in 3D — collisions, access and maintenance space resolved before installation.

Digital prototypeFit, motion and assembly checked in the model; then STL/3MF for 3D printing of a physical sample.

3D printing

From digital model to physical prototype

We quickly turn digital models into physical prototypes, functional parts or presentation samples — housings, brackets, scale models and concept prototypes. Ideal for checking an idea before investing in tooling or a production run.

ModelYour file or ours — checked for wall thickness, overhangs and tolerances for printing.

PreparationOrientation, supports and slicing; material chosen for the job — PLA, PETG or ASA.

PrintFDM printing of functional parts, housings, brackets, jigs and scale models.

Finishing & checkSupport removal, threads and inserts, dimensional check against the model.

For quotes and presentations

A render in the offer shows the client exactly what they are buying — fewer questions, faster decisions, stronger position against competitors who send a table and a sketch.

For product development
